Technical Standard:
Nominal Pressure : 1.6MPa
Working Temprature: 0°C≤t≤50°C
Pipe Thread to ISO228
Electric Voltage :24VAC,120VAC,220VAC,240VAC
Power consumption: 2VA
Scope :3mm (Max.5mm)
Whole distance time :5-10 Seconds
Item Model | Thread | Kv flow ratio | Close pressure |
VA-7010-8503-215 | G½" | 1.6 | 0.25 MPa |
VA-7010-8503-220 | G¾" | 2.5 | 0.1 MPa |
VA-7010-8503-225 | G1" | 4.0 | 0.06MPa |
