Multijet Dry Dial Rotary Vane Wheel Pulse Output Water Meter LXSY-15G

Features:

Multi-jet water meter, easy for maintenance;

Magnetic drive reliable characteristic, long working life;

Vacuum sealed register ensures the dial keep free from fog and frost, Keep the reading clear in a long term service;

Technical data conform to international standard ISO4064 Class B.

Freezing resistance

One signal per 10 liters or 1000 liters, allowing for remote monitoring and integration with automated systems for data collection and analysis.

Application:

The Multijet Dry Dial Rotary Vane Wheel Pulse Output Water Meter LXSY-15G is commonly used in various applications for measuring the flow rate of water, with an electrical output, in residential and commercial applications.

Working Condition:

Cold water temperature≤40℃

Hot water temperature≤90℃

Water pressure≤1.0Mpa

Immersion the water meter into water is not allowed

Type of Signal:

Reed switch or Hall Elemant pulse.

Notice the special note when ordering with the Hall Element pulse  Maximum Permissible Error

±5% at the Low-Zone ranging from min flow/Qmin (including Qmin) to transitional flow/Qt (excluding Qt).

±2% at the High-Zone ranging from transitional flow/Qt to max flow/QS (both Qt and Qs included), if for hot water meter, ±3% error acceptable.
